Aluminium Alloy Energy Saving Sectional Door Corrosion Resistant For Port Logistics Buildings

Aluminium Alloy Energy Saving Sectional Door Corrosion Resistant For Port Logistics Buildings

aluminium alloy sectional overhead door

aluminium alloy industrial overhead sectional door

24db sectional overhead door

Place of Origin:

China

Brand Name:

YOHO

Certification:

ISO 9001/CE

Model Number:

Sectional Overhead Door

Chat Now
Request A Quote
Product Details
Product Name:
Sectional Overhead Door
Material:
SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate
Thickness Of Panel Mateiral:
0.3–0.6 Mm Galvanized Color-Coated Steel Sheet
Thickness Of Panel:
40mm, 50mm, And 80mm
Maximum Available Size:
Door Width: 1000mm–8000mm, Door Height: 1500mm–10000mm
Size:
Customized Size
Speed:
10-15m/min
Sound Insulation:
24dB
Watertight:
Level 3 (water Pressure 30Pa)
Application:
Port Logistics Buildings
Highlight:

aluminium alloy sectional overhead door

,

aluminium alloy industrial overhead sectional door

,

24db sectional overhead door

Payment & Shipping Terms
Minimum Order Quantity
IUNIT
Price
Negotiable
Packaging Details
plywood package
Delivery Time
10~15DAYS
Payment Terms
T/T
Supply Ability
300 unit per month
Product Description

Industrial Sectional Overhead Door for Port Logistics Buildings

Port logistics buildings manage the loading, unloading, and storage of containerized and bulk cargo transported via ships, trucks, and cranes. Doors in these facilities must withstand frequent operation, heavy cargo vehicles, and exposure to humid or corrosive maritime environments. An Industrial Sectional Overhead Door offers a robust lift-up solution that maximizes workflow efficiency, ensures safety, and maintains durability in port logistics operations.


Why Sectional Overhead Doors Are Essential in Port Logistics

High-Frequency Cargo Handling

Doors handle continuous movements of goods between ships, trucks, and storage areas.

Accommodation for Large Vehicles and Containers

Wide and tall openings allow forklifts, container trucks, and cranes to pass efficiently.

Space-Saving Vertical Lift Design

Keeps floor space clear for large-scale cargo operations and material handling.

Aluminium Alloy Energy Saving Sectional Door Corrosion Resistant For Port Logistics Buildings 0 Aluminium Alloy Energy Saving Sectional Door Corrosion Resistant For Port Logistics Buildings 1

Product Specifications

Item Description
Material SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate
Thickness of Panel Mateiral 0.3-0.6mm Color Coating Plate
Thickness of Guiding Rail Gualvanized Steel,thickness: 2mm
Thickness of Panel 40mm / 50mm /80mm
Width of Panel 430mm / 550mm
Density of Sandwiches 48kg/m3
Surface Treatment Power coating,thickness of coating:30um
Heat Preservation 4.5W/m.h
Wind Resistance Beaufort scale 11, 28m/s
Noise Level: ≤60db
Sound Insulation Level 24 Db
Fire Retardation: Class A
Speed 10-15 m / min
Max Dimension 12m * 8m
Sealing Performance EPDM rubber all round sealing : two side, top, bottom,between door panels
Steel cord Flexible ,3.8mm
Power Supply 380V 50Hz / 220V 50Hz
Service Life 10 years
Emergency Operation Manual Hoist Chain to open the door in case of power off
Balance System a. Balance the weight of door through the torsion spring
b. Easily manual operation: 140N to open
c. Spring brake device:Anti-broken device
d. Service Life:100 thousand open & close
e. Prolong the service life of the motor
Safety Airbag protection, door anti-fall device, wire rope anti-break protection device.
Optional Item Window,pedestrian door


Aluminium Alloy Energy Saving Sectional Door Corrosion Resistant For Port Logistics Buildings 2


Core Features for Port Logistics Applications

Heavy-Duty Panels with Corrosion Resistance

Steel or aluminum panels withstand impact, abrasion, and humid conditions.

Reinforced Tracks & Balanced Spring Mechanism

Ensures smooth, reliable operation under high-frequency cycles.

Effective Sealing & Environmental Protection

Protects stored cargo from dust, salt air, and external elements.


Typical Applications in Port Logistics Buildings

Inbound Cargo Reception Zones

Supports unloading from ships and delivery trucks.

Sorting, Storage, & Container Staging Areas

Facilitates organization and temporary holding of goods.

Outbound Shipping & Loading Areas

Streamlines cargo transfer to trucks, ships, or rail.

Maintenance & Equipment Storage Sections

Provides safe access for forklifts, cranes, pallets, and tools.

Installation method

Aluminium Alloy Energy Saving Sectional Door Corrosion Resistant For Port Logistics Buildings 3

Contact Us:

Email:yohao260105@gmail.com

Whatsapp:+8618021983369

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service

FAQ – Port Logistics Buildings

Can sectional overhead doors handle containerized cargo?

Yes, they are designed for heavy-duty, high-frequency industrial operations.

Are insulated doors necessary in port facilities?

Insulation is optional, depending on cargo type and storage requirements.

Is automatic operation recommended?

Yes, automatic doors improve efficiency in main cargo bays and high-traffic areas.


Aluminium Alloy Energy Saving Sectional Door Corrosion Resistant For Port Logistics Buildings 4

Aluminium Alloy Energy Saving Sectional Door Corrosion Resistant For Port Logistics Buildings 5

Get a Door Solution for Port Logistics Buildings

Project Consultation & Technical Support

Expert guidance for door selection, sizing, and integration with port operations.

Bulk Supply & OEM Solutions

Suitable for port operators, logistics providers, and large-scale projects.
