Place of Origin:
China
Brand Name:
YOHO
Certification:
ISO 9001/CE
Model Number:
Sectional Overhead Door
Regional distribution centers operate around the clock, handling large volumes of goods between manufacturers, warehouses, and retail locations. Frequent truck loading, forklift traffic, and continuous material handling require a reliable door system that keeps logistics moving efficiently. Our Industrial Sectional Overhead Door is designed to improve operational efficiency, reduce energy loss, and provide long-lasting performance for modern distribution facilities.
Built with heavy-duty tracks, torsion springs, and industrial-grade motors, the door delivers smooth and reliable operation in high-cycle distribution environments.
Polyurethane-filled insulated panels and full EPDM perimeter seals help maintain indoor temperatures while reducing dust, wind, and moisture infiltration.
Integrated spring break protection, cable safety devices, anti-fall systems, and emergency manual operation ensure safe daily use.
Available with standard lift, high lift, and vertical lift configurations to suit different building layouts and ceiling heights.
Optional vision panels, pedestrian doors, remote control, and automation systems can be configured to meet specific operational requirements.
|
|
|
Distribution center operators focus on speed, reliability, and cost control. Every loading dock delay affects delivery schedules and customer satisfaction.
Fast and stable door operation reduces waiting time for trucks and forklifts, helping increase daily throughput.
Insulated panels reduce heat loss and support a more energy-efficient warehouse environment.
Superior sealing keeps dust, rain, and outside air away from valuable inventory.
Industrial-grade components are engineered for frequent operation, minimizing maintenance costs and unexpected interruptions.
The vertical lifting design keeps entrances clear, allowing smooth movement of pallets, forklifts, and loading equipment.
| Item | Description |
|---|---|
| Material | SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate |
| Thickness of Panel Mateiral | 0.3 - 0.6mm Color-Coated Steel |
| Thickness of Guiding Rail | Gualvanized Steel,thickness: 2mm |
| Thickness of Panel | 40mm / 50mm / 80mm |
| Width of Panel | 430mm / 550mm |
| Density of Sandwiches | 48kg/m3 |
| Surface Treatment | Power coating,thickness of coating:30um |
| Heat Preservation | 4.5W/m.h |
| Wind Resistance | Beaufort scale 11, 28m/s |
| Noise Level: | ≤60db |
| Sound Insulation Level | 24 Db |
| Fire Retardation: | Class A |
| Speed | 10-15 m / min |
| Max Dimension | 12m * 8m |
| Sealing Performance | EPDM rubber all round sealing : two side, top, bottom,between door panels |
| Steel cord | Flexible ,3.8mm |
| Power Supply | 380V 50Hz / 220V 50Hz |
| Service Life | 10 years |
| Emergency Operation | Manual Hoist Chain to open the door in case of power off |
| Balance System | a. Balance the weight of door through the torsion spring b. Easily manual operation: 140N to open c. Spring brake device:Anti-broken device d. Service Life:100 thousand open & close e. Prolong the service life of the motor |
| Safety | Airbag protection, door anti-fall device, wire rope anti-break protection device. |
| Optional Item | Window,pedestrian door |
Contact Us:
Whatsapp:+8618021983369
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Changzhou YOHO Industrial Door Co., Ltd. is a professional manufacturer specializing in industrial door systems and loading dock equipment for warehouses, logistics centers, manufacturing plants, and commercial facilities.
Our factory combines advanced production equipment, experienced engineers, and strict quality control to deliver reliable Industrial Sectional Overhead Doors for global B2B customers.
|
|
|
Yes. It is specifically designed for high-frequency operations where trucks and forklifts move continuously throughout the day.
Yes. Insulated door panels and high-quality sealing reduce heat transfer and improve energy efficiency.
Yes. The door can work together with dock levelers, dock shelters, and warehouse automation systems to improve loading efficiency.
Absolutely. We offer customized dimensions, panel thickness, lifting methods, colors, windows, pedestrian doors, and control systems based on your project.
Looking for a dependable Industrial Sectional Overhead Door for your regional distribution center?
Changzhou YOHO Industrial Door Co., Ltd. offers factory-direct manufacturing, OEM solutions, technical support, and competitive pricing for distributors, contractors, logistics companies, and project buyers worldwide.
