Improve Logistics Efficiency Industrial High Speed Door For Loading Docks
  • name
  • name

Improve Logistics Efficiency Industrial High Speed Door For Loading Docks

MOQ: IUNIT
Price: negotiation
Standard Packaging: plywood package
Delivery Period: 10~15DAYS
Payment Method: T/T
Supply Capacity: 300 unit per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
YOHO
Certification
ISO 9001/CE
Model Number
High-Speed PVC Industrial Door
Color:
Yellow/Blue/Red/Grey/White/Transparent
Size:
3x3 M Or Customized (max Size:6x8m)
Voitage:
380V Or 220V
Name:
High-Speed PVC Industrial Door
Panel Material:
Anti-skid Checkered Plate
Material:
PVC Curtain / Galvanized Steel / Stainless Steel
Power:
0.75-1.5KW
Door Width:
1000 Mm - 6000 Mm
Door Height:
1500 Mm - 6000 Mm
Application:
Loading Docks
Highlight:

pvc industrial high speed door

,

red industrial high speed door

Product Description

Improve Logistics Efficiency Industrial High Speed Door For Loading Docks

The Industrial High Speed Door for Loading Docks is designed to improve logistics efficiency, energy control, and safety at warehouse and distribution center loading areas.

Loading docks experience frequent opening, strong airflow, vehicle movement, and temperature exchange between indoor and outdoor environments. This high speed door features fast operation, reinforced structure, and tight sealing, helping reduce air loss, prevent dust and insects, and support smooth loading and unloading operations.

Product Specifications

Material PVC curtain / Galvanized steel / Stainless steel
Max Door Size Door Width: 1000 mm - 6000 mm; Door Height: 1500 mm - 6000 mm
Operating Speed Opening Speed: 0.6 - 1.2 m/s (adjustable); Closing Speed: 0.6 m/s (adjustable)
Curtain Material 0.8 - 2.0 mm thick curtain, color options: Blue, Orange, Gray
Motor Power 0.75-1.5KW (depending on size & speed)
Temperature Range -10°C to 60°C (PVC); -10°C to 60°C (Steel/Stainless Steel)
Sealing Performance High-quality brush seals on tracks; Bottom equipped with EPDM seal structure for optimal sealing
Wind Resistance Max Wind Resistance: Class 6 (can be reinforced to Class 8)
Manual Function In case of power failure or malfunction, the door can be manually opened with a wrench
Power Requirements 220V/13A Single-phase/50Hz-60Hz, IP54 control box, meets national electrical safety standards
Insulation Protection IP54 rating, providing water and dust protection, suitable for harsh environments
Switching Methods Standard one-button switch with emergency stop. Optional: Radar sensing, Ground magnetic sensing, Pull-rope switch, Remote control

Wind Resistance & Sealing Performance

Loading docks face strong airflow caused by open doors and vehicle movement.

  • Reinforced Curtain: Thickness up to 2.0 mm improves stability
  • Wind Resistance: Standard Grade 6, optional upgrade to Grade 8
  • Bottom Airbag or Soft Edge: Improves sealing against uneven dock floors
  • Fast Opening Speed: Reduces exposure time to outdoor conditions

Product Features

  • High-Speed Operation: Opening speed up to 1.2–1.5 m/s, adjustable
  • Large Door Dimensions: Width up to 6000 mm, height up to 6000 mm
  • Servo Control System: DSP-based servo controller with encoder feedback and LED fault display
  • Curtain Material: PVC curtain 0.8–2.0 mm, optional reinforced or insulated curtain
  • Wind Resistance: Standard Grade 6, reinforced up to Grade 8
  • Sealing System: Side brush seals + EPDM bottom soft edge or airbag sealing
  • Frame Material: Galvanized steel with powder coating (standard), stainless steel optional
  • Safety Devices: Infrared photoelectric sensors, bottom safety edge, emergency stop
  • Activation Methods: Push button, radar sensor, ground loop, pull rope, remote control
  • Emergency Operation: Manual opening during power failure

FAQ

Q1: Why use high speed doors at loading docks?

They reduce air loss, improve safety, and increase efficiency during frequent loading and unloading operations.

Q2: Can the door withstand outdoor wind pressure?

Yes. The door offers Grade 6 wind resistance, reinforced up to Grade 8, suitable for dock environments.

Q3: Is the door compatible with dock levelers or shelters?

Yes. It can be integrated with dock levelers, dock shelters, and logistics automation systems.

Q4: Does the door support high-frequency operation?

Yes. The servo motor system supports thousands of cycles per day without performance loss.

Improve Logistics Efficiency Industrial High Speed Door For Loading Docks 0

Improve Logistics Efficiency Industrial High Speed Door For Loading Docks 1
