PVC Customized High Speed Stacking Door With Automatic Fast Stacking Rolling Curtain Rapid Door
  • name
  • name

PVC Customized High Speed Stacking Door With Automatic Fast Stacking Rolling Curtain Rapid Door

MOQ: IUNIT
Price: negotiation
Standard Packaging: plywood package
Delivery Period: 10~15DAYS
Payment Method: T/T
Supply Capacity: 300 unit per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
YOHO
Certification
ISO 9001/CE
Model Number
High Speed Stacking Door
Color:
Yellow/Blue/Red/Grey/White/Transparent
PVC Door Curtain Thickness:
0.8–1.2 Mm
Size:
3x3 M Or Customized (max Size:6x8m)
Voitage:
380V Or 220V
Name:
High-Speed PVC Industrial Door
Panel Material:
Anti-skid Checkered Plate
Material:
PVC Curtain / Galvanized Steel / Stainless Steel
Power:
0.75-1.5KW
Door Width:
1000mm–12000mm
Door Height:
1500mm–12000mm
Opening Speed:
0.6–1.2 M/s (adjustable)
Closing Speed:
0.6 M/s (adjustable)
Application:
Equipment Manufacturing Factories
Highlight:

Customized High Speed Stacking Door

,

PVC High Speed Stacking Door

,

Rolling Curtain Rapid Door

Product Description

PVC Customize High Speed Stacking Door With Automatic Fast Stacking Rolling Curtain Rapid Door For Equipment Manufacturing Factories

The High Speed Stacking Door is a Heavy Duty High Speed Door developed for equipment manufacturing factories where large machinery, steel frames, and heavy components frequently pass through production entrances. As an advanced Industrial High Speed Door, it combines fast operation with structural strength, ensuring safety and efficiency in demanding industrial environments.

Product Specifications

Parameter Description
Special Door Type High Speed Stacking Door
Opening Method Electric Side Opening
Maximum Dimensions Door width: 1000mm–12000mm, Door height: 1500mm–12000mm
Operating Speed Opening speed: 0.6–1.2 m/s (adjustable)
Closing speed: 0.6 m/s (adjustable)
Door Curtain Material 0.8–1.2 mm thick curtain; available colors: Blue, Orange, Gray
Frame Material Standard track frame: Galvanized steel with powder coating
Optional upgrade: Stainless steel
Project Solution Capability 3D model design
Surface Finishing Finished
Sealing Performance High-quality brush sealing on tracks, bottom equipped with EPDM sealing structure
Wind Resistance Up to Class 6 wind, can be reinforced to Class 8
Manual Operation In case of power failure or malfunction, the door can be manually opened using a standard wrench
Power Supply Requirements Three-phase 380V/50Hz, IP54 control box, compliant with national electrical safety standards
Insulation Protection IP54, waterproof and dustproof for harsh environments
Opening/Closing Control Standard one-button operation with emergency stop; optional control methods: Radar sensor, loop detector, pull cord switch, remote control
Pre-reserved Ports Electrical system pre-reserved for: infrared safety switch, loop detector, radar sensor, pull cord switch, remote control, dual-door interlock; highly compatible
Control System (Servo System) Uses dedicated servo system with DSP chip core
System sets door opening height based on incremental encoder signals from the motor and limit switch signals
LED display shows fault codes
Direction protection: controller reports error if motor wiring is reversed; door remains stationary
Torque loop, position loop, and speed loop fully closed
Motor can stop at exact position without using an electromagnetic brake

The component of product

PVC Customized High Speed Stacking Door With Automatic Fast Stacking Rolling Curtain Rapid Door 0

Product Features

  • Heavy-duty stacking curtain structure
  • High frequency industrial door design
  • Stable operation under vibration
  • Automatic industrial control system

Product Advantages

  • Designed for heavy machinery movement
  • Long service life with low maintenance
  • Handles frequent forklift traffic
  • Improves workshop workflow efficiency

Applications

  • Machinery assembly workshops
  • Equipment manufacturing plants
  • Industrial fabrication facilities

Feature Highlight: Heavy Duty Structure

This heavy duty high speed door uses reinforced materials to withstand demanding equipment manufacturing environments.

FAQ

Q1: Is this door suitable for heavy industry?
Yes, it is widely used as a High Speed Door for Heavy Industry.

Q2: Can it handle large door sizes?
Yes, it is ideal for High Speed Door for Large Openings.

Q3: Does it support automation systems?
Yes, it can integrate with PLC and industrial control systems.

Q4: Is it more durable than roll up doors?
Yes, stacking doors are more stable for large industrial entrances.

PVC Customized High Speed Stacking Door With Automatic Fast Stacking Rolling Curtain Rapid Door 1

PVC Customized High Speed Stacking Door With Automatic Fast Stacking Rolling Curtain Rapid Door 2
