High Performance High Speed Stacking Door With Double-sided Manual Button For New Energy Manufacturing Plants
  • name
  • name

High Performance High Speed Stacking Door With Double-sided Manual Button For New Energy Manufacturing Plants

MOQ: IUNIT
Price: negotiation
Standard Packaging: plywood package
Delivery Period: 10~15DAYS
Payment Method: T/T
Supply Capacity: 300 unit per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
YOHO
Certification
ISO 9001/CE
Model Number
High Speed Stacking Door
Color:
Yellow/Blue/Red/Grey/White/Transparent
PVC Door Curtain Thickness:
0.8–1.2 Mm
Size:
3x3 M Or Customized (max Size:6x8m)
Voitage:
380V Or 220V
Name:
High-Speed PVC Industrial Door
Panel Material:
Anti-skid Checkered Plate
Material:
PVC Curtain / Galvanized Steel / Stainless Steel
Power:
0.75-1.5KW
Door Width:
1000mm–12000mm
Door Height:
1500mm–12000mm
Opening Speed:
0.6–1.2 M/s (adjustable)
Closing Speed:
0.6 M/s (adjustable)
Application:
New Energy Manufacturing Plants
Highlight:

pvc industrial high speed door

,

red industrial high speed door

Product Description

High Performance High Speed Stacking Door With Double-sided Manual Button For New Energy Manufacturing Plants

The High Speed Stacking Door is a heavy-duty Industrial High Speed Stacking Door designed for new energy manufacturing plants where large equipment, automated logistics, and frequent material transfer are part of daily operations. Compared with traditional roll up doors, this Stacking High Speed Door is specially engineered for large openings, strong wind resistance, and stable high-cycle performance, making it ideal for lithium battery, photovoltaic, and EV component factories.

Product Specifications

Parameter Description
Special Door Type High Speed Stacking Door
Opening Method Electric Side Opening
Maximum Dimensions Door width: 1000mm–12000mm, Door height: 1500mm–12000mm
Operating Speed Opening speed: 0.6–1.2 m/s (adjustable)
Closing speed: 0.6 m/s (adjustable)
Door Curtain Material 0.8–1.2 mm thick curtain; available colors: Blue, Orange, Gray
Frame Material Standard track frame: Galvanized steel with powder coating
Optional upgrade: Stainless steel
Project Solution Capability 3D model design
Surface Finishing Finished
Sealing Performance High-quality brush sealing on tracks, bottom equipped with EPDM sealing structure
Wind Resistance Up to Class 6 wind, can be reinforced to Class 8
Manual Operation In case of power failure or malfunction, the door can be manually opened using a standard wrench
Power Supply Requirements Three-phase 380V/50Hz, IP54 control box, compliant with national electrical safety standards
Insulation Protection IP54, waterproof and dustproof for harsh environments
Opening/Closing Control Standard one-button operation with emergency stop; optional control methods: Radar sensor, loop detector, pull cord switch, remote control
Pre-reserved Ports Electrical system pre-reserved for: infrared safety switch, loop detector, radar sensor, pull cord switch, remote control, dual-door interlock; highly compatible
Control System (Servo System) Uses dedicated servo system with DSP chip core

System sets door opening height based on incremental encoder signals from the motor and limit switch signals

LED display shows fault codes

Direction protection: controller reports error if motor wiring is reversed; door remains stationary

Torque loop, position loop, and speed loop fully closed

Motor can stop at exact position without using an electromagnetic brake

The component of product

High Performance High Speed Stacking Door With Double-sided Manual Button For New Energy Manufacturing Plants 0

Options of Door Opening ways

our door's opening way has the push buttom,motion sensor,induction loop,remote control,pull swith,infrared light curtain and so on.

High Performance High Speed Stacking Door With Double-sided Manual Button For New Energy Manufacturing Plants 1

Key Features

  • Large opening High Speed Stack Door structure for oversized industrial entrances
  • Wind resistant design suitable for semi-outdoor factory buildings
  • High frequency industrial door system supports continuous operation
  • Fast opening industrial door reduces waiting time for AGVs and forklifts

Advantages for New Energy Factories

  • Ensures smooth logistics flow between production lines and warehouses
  • Reduces energy loss caused by long door opening times
  • Withstands airflow pressure from large factory buildings
  • Durable high speed door structure for 24/7 industrial operation

Typical Applications

  • Battery module assembly plants
  • Photovoltaic panel manufacturing workshops
  • EV parts production facilities
  • Automated logistics corridors

Feature Highlight: Large Opening & Stable Operation

New energy factories often require large opening high speed doors. This stacking high speed door maintains stability at wide spans while ensuring fast opening and closing, preventing workflow bottlenecks.

FAQ

Q1: Is this door suitable for large equipment access?

Yes, it is designed as a Large Opening High Speed Door for oversized entrances.

Q2: Can it handle high-frequency operation?

Absolutely. It is a High Frequency Industrial Door for continuous use.

Q3: Is wind resistance important for new energy plants?

Yes, especially in large-span factory buildings with strong airflow.

Q4: Can the door be customized?

Yes, it supports Custom Industrial High Speed Door configurations.

High Performance High Speed Stacking Door With Double-sided Manual Button For New Energy Manufacturing Plants 2

High Performance High Speed Stacking Door With Double-sided Manual Button For New Energy Manufacturing Plants 3
