Curtain Thick 0.8mm–1.2mm High Speed Stacking Door For Electronics Workshops
  • name
  • name

Curtain Thick 0.8mm–1.2mm High Speed Stacking Door For Electronics Workshops

MOQ: IUNIT
Price: negotiation
Standard Packaging: plywood package
Delivery Period: 10~15DAYS
Payment Method: T/T
Supply Capacity: 300 unit per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
YOHO
Certification
ISO 9001/CE
Model Number
High Speed Stacking Door
Name:
High Speed Stacking Door
Color:
Yellow/Blue/Red/Grey/White/Transparent
PVC Door Curtain Thickness:
0.8–1.2 Mm
Voitage:
380V Or 220V
Panel Material:
Anti-skid Checkered Plate
Material:
PVC Curtain / Galvanized Steel / Stainless Steel
Power:
0.75-1.5KW
Size:
3x3 M Or Customized (max Size:6x8m)
Door Width:
1000mm–12000mm
Door Height:
1500mm–12000mm
Opening Speed:
0.6–1.2 M/s (adjustable)
Closing Speed:
0.6 M/s (adjustable)
Application:
Electronics Workshops
Highlight:

0.8mm High Speed Stacking Door

,

1.2mm High Speed Stacking Door

,

Electronics Workshops High Speed Stacking Door

Product Description

0.8–1.2 Mm Thick Curtain High-speed Stacking Doors For Electronics Workshops

The High Speed Stacking Door for electronics workshops is engineered to maintain clean environments, ensure safety, and improve workflow efficiency.

In electronics production, dust, airflow, and static control are critical. This door combines a fast-opening insulated PVC curtain, robust servo-controlled motor system, and advanced safety features to support high-frequency operation while maintaining internal environmental stability.

Note: Suitable for ambient-temperature areas only. Not recommended for cold storage or sub-zero conditions.

Product Parameters

Parameter Description
Maximum Dimensions Door width: 1000mm–12000mm, Door height: 1500mm–12000mm
Operating Speed Opening speed: 0.6–1.2 m/s (adjustable)
Closing speed: 0.6 m/s (adjustable)
Door Curtain Material 0.8–1.2 mm thick curtain; available colors: Blue, Orange, Gray
Frame Material Standard track frame: Galvanized steel with powder coating
Optional upgrade: Stainless steel
Sealing Performance High-quality brush sealing on tracks, bottom equipped with EPDM sealing structure
Wind Resistance Up to Class 6 wind, can be reinforced to Class 8
Manual Operation In case of power failure or malfunction, the door can be manually opened using a standard wrench
Power Supply Requirements Three-phase 380V/50Hz, IP54 control box, compliant with national electrical safety standards
Insulation Protection IP54, waterproof and dustproof for harsh environments
Opening/Closing Control Standard one-button operation with emergency stop; optional control methods: Radar sensor, loop detector, pull cord switch, remote control
Pre-reserved Ports Electrical system pre-reserved for: infrared safety switch, loop detector, radar sensor, pull cord switch, remote control, dual-door interlock; highly compatible

Control System (Servo System)

  • Uses dedicated servo system with DSP chip core
  • System sets door opening height based on incremental encoder signals from the motor and limit switch signals
  • LED display shows fault codes
  • Direction protection: controller reports error if motor wiring is reversed; door remains stationary
  • Torque loop, position loop, and speed loop fully closed
  • Motor can stop at exact position without using an electromagnetic brake

Product Advantages

Maintain Clean Production Areas

  • Smooth PVC curtain reduces dust accumulation

  • Tight sealing minimizes airflow contamination

High Workflow Efficiency

  • Fast opening and closing for uninterrupted internal traffic

  • Supports high-frequency use for busy electronics production lines

Safety & Reliability

  • Infrared sensors and bottom soft edge prevent accidents

  • Servo-controlled system ensures precise stopping and rebound

Energy Efficiency

  • EPDM bottom seal and track brush reduce air exchange

  • Helps maintain temperature and energy savings

Applications

The High Speed Stacking Door is ideal for electronics workshops:

  • Internal passages between assembly, testing, and packaging zones

  • High-traffic corridors for personnel and material handling

  • Ambient-temperature sections requiring dust and airflow control

  • Areas needing fast, safe, and frequent door operation

FAQ

Can this door be used in cleanrooms?

Yes, it is suitable for ambient-temperature controlled environments, but not for ISO-classified cleanrooms requiring sub-zero operation.

Is it safe for frequent operation?

Yes. The servo motor system supports thousands of cycles per day, ideal for busy electronics workshops.

Can the door size and frame material be customized?

Yes. Width, height, curtain thickness, and frame material (galvanized steel or stainless steel) can be customized.

Curtain Thick 0.8mm–1.2mm High Speed Stacking Door For Electronics Workshops 0

Curtain Thick 0.8mm–1.2mm High Speed Stacking Door For Electronics Workshops 1
