Multi-Mode Activation PVC High Speed Door with Adjustable Speed for Mixed Workflow Traffic

Multi-Mode Activation PVC High Speed Door with Adjustable Speed for Mixed Workflow Traffic

Multi-Mode Activation High Speed Door

Flexible Activation Options Door

Pull Cord Remote Control Door

Place of Origin:

China

Brand Name:

YOHO

Certification:

ISO 9001/CE

Model Number:

YOHO-PVC-HSD-MM

Chat Now
Request A Quote
Multi-Mode Activation PVC High Speed Door with Adjustable Speed for Mixed Workflow Traffic Multi-Mode Activation PVC High Speed Door with Adjustable Speed for Mixed Workflow Traffic Multi-Mode Activation PVC High Speed Door with Adjustable Speed for Mixed Workflow Traffic
Product Details
Activation Options:
Radar Sensor, Pull-cord Switch, Remote Control, Loop Detector, Push Button
Opening Speed:
0.8-2.0 M/s (adjustable)
Closing Speed:
0.5-0.8 M/s (adjustable)
Max Door Size:
Width 1000-6000 Mm; Height 1500-6000 Mm
Curtain Material:
PVC, 0.8-2.0 Mm Thickness
Frame Material:
Galvanized Steel / Stainless Steel
Motor Power:
0.75-1.5 KW
Control System:
DSP Servo System With LED Fault Display
Sealing System:
Side Brush Seals With Bottom Airbag / EPDM Seal
Operating Temperature:
-10 C To 60 C
Voltage:
220V/380V, 50Hz-60Hz
Highlight:

Multi-Mode Activation High Speed Door

,

Flexible Activation Options Door

,

Pull Cord Remote Control Door

Payment & Shipping Terms
Minimum Order Quantity
1 Unit
Price
USD 900-2500 / Unit
Packaging Details
Plywood case with protective film and shock-proof packing
Delivery Time
10-15 working days
Payment Terms
T/T
Supply Ability
300 Units per Month
Related Products
Good price Custom Color Configuration PVC High Speed Door with Custom Dimensions and Activation for Industrial Use online

Custom Color Configuration PVC High Speed Door with Custom Dimensions and Activation for Industrial Use

Chat Now
Good price Replaceable Curtain PVC High Speed Door with DSP Servo System for Easy Maintenance online

Replaceable Curtain PVC High Speed Door with DSP Servo System for Easy Maintenance

Chat Now
Good price Quick Access Component PVC High Speed Door with Replaceable Curtain and DSP Servo System online

Quick Access Component PVC High Speed Door with Replaceable Curtain and DSP Servo System

Chat Now
Good price Motorized Servo Drive PVC High Speed Door for 1000+ Cycles Daily with Adjustable Speed 0.8-2.0 m/s online

Motorized Servo Drive PVC High Speed Door for 1000+ Cycles Daily with Adjustable Speed 0.8-2.0 m/s

Chat Now
Contact Us
86--18021983369
yohao260105@gmail.com
Chat Now
Product Description
Multi-Mode Activation PVC Industrial High Speed Door For Mixed Workflow Traffic Patterns
Different doorways serve different traffic patterns. Some handle regular vehicle flow, others see foot traffic, carts, and equipment at different times of day. A single fixed switch rarely fits them all. This Industrial High Speed Door is built around one core selling point: flexible activation options for different workflows. Radar, pull-cord switches, remote controls, loop detectors, and push buttons can be selected to suit different traffic patterns, giving one door the flexibility to handle mixed workflows efficiently.
Flexible Activation Highlights
  • Radar Sensors: Automatic detection for vehicle or equipment traffic, no contact required.
  • Pull-Cord Switch: A simple pull cord lets anyone trigger the door from either side.
  • Remote Control: Operators can open and close the door from a distance for convenience.
  • Loop Detectors: Ground loop detection supports smooth vehicle flow through the opening.
  • Push Button: Standard one-button operation with emergency stop for manual control.
  • Combine As Needed: Multiple activation methods can be mixed to match different workflows and traffic patterns.
Why It Improves Workflow
  • One Door, Many Workflows: Select the activation method that fits each traffic pattern.
  • Smooth Mixed Traffic: Support pedestrians, carts, and vehicles through a single opening.
  • Faster Cycle Times: The right trigger for each situation reduces waiting and keeps things moving.
  • Operator Convenience: Remote and pull-cord options suit different users and situations.
  • Reliable Operation: LED fault display and emergency manual override support safe, dependable use.
Typical Applications
  • Multi-purpose doorways with mixed traffic
  • Warehouses handling both vehicles and personnel
  • Production areas with carts and pedestrian flow
  • Facilities with varying traffic throughout the day
  • Any opening needing adaptable activation
Product Specifications
Activation Options Radar sensor, pull-cord switch, remote control, loop detector, push button
Material PVC curtain / Galvanized steel (standard), stainless steel optional
Max Door Size Width 1000-6000 mm, Height 1500-6000 mm
Operating Speed Opening 0.8-2.0 m/s (adjustable); Closing 0.5-0.8 m/s (adjustable)
Curtain Thickness 0.8 / 1.2 / 1.5 / 2.0 mm
Motor Power 0.75-1.5 KW (depending on size and speed)
Sealing System Side brush seals with bottom airbag / EPDM seal
Control System DSP-based servo system with LED fault display
Temperature Range -10°C to 60°C
Power Requirements 220V/13A single-phase, 50Hz-60Hz, IP54 control box
Frequently Asked Questions
  • Can one door support multiple activation methods? Yes, radar, loop, remote, pull-cord, and push button can be combined to suit your traffic.
  • Which activation suits my workflow? We help you select radar or loop for vehicles, and pull-cord, remote, or button for pedestrian and mixed traffic.
  • Can it be customized? Yes, dimensions, curtain material, activation methods, and control options are customizable.
Contact Us
Changzhou YOHO Industrial Door Co., Ltd.
Email: yohao260105@gmail.com
WhatsApp: +8618021983369
OEM & ODM welcome. Contact us today for factory-direct pricing and customized activation solutions.
