Photoelectric Sensor Industrial High Speed Door with Emergency Stop and DSP Servo System for Enhanced Safety

Photoelectric Sensor Industrial High Speed Door with Emergency Stop and DSP Servo System for Enhanced Safety

Photoelectric Sensor Safety Door

Mixed Traffic Safety High Speed Door

Forklift Pedestrian Protection Door

Place of Origin:

China

Brand Name:

YOHO

Certification:

ISO 9001/CE

Model Number:

YOHO-PVC-HSD-SF

Chat Now
Request A Quote
Photoelectric Sensor Industrial High Speed Door with Emergency Stop and DSP Servo System for Enhanced Safety Photoelectric Sensor Industrial High Speed Door with Emergency Stop and DSP Servo System for Enhanced Safety Photoelectric Sensor Industrial High Speed Door with Emergency Stop and DSP Servo System for Enhanced Safety
Product Details
Safety System:
Photoelectric Sensors, Optional Safety Bottom Edge, Reverse Wiring Protection
Emergency Stop:
Standard Emergency Stop Switch
Opening Speed:
0.8-2.0 M/s (adjustable)
Closing Speed:
0.5-0.8 M/s (adjustable)
Max Door Size:
Width 1000-6000 Mm; Height 1500-6000 Mm
Curtain Material:
PVC, 0.8-2.0 Mm Thickness
Frame Material:
Galvanized Steel / Stainless Steel
Motor Power:
0.75-1.5 KW
Control System:
DSP Servo System With LED Fault Display
Operating Temperature:
-10 C To 60 C
Voltage:
220V/380V, 50Hz-60Hz
Highlight:

Photoelectric Sensor Safety Door

,

Mixed Traffic Safety High Speed Door

,

Forklift Pedestrian Protection Door

Payment & Shipping Terms
Minimum Order Quantity
1 Unit
Price
USD 900-2500 / Unit
Packaging Details
Plywood case with protective film and shock-proof packing
Delivery Time
10-15 working days
Payment Terms
T/T
Supply Ability
300 Units per Month
Related Products
Good price Custom Color Configuration PVC High Speed Door with Custom Dimensions and Activation for Industrial Use online

Custom Color Configuration PVC High Speed Door with Custom Dimensions and Activation for Industrial Use

Chat Now
Good price Replaceable Curtain PVC High Speed Door with DSP Servo System for Easy Maintenance online

Replaceable Curtain PVC High Speed Door with DSP Servo System for Easy Maintenance

Chat Now
Good price Quick Access Component PVC High Speed Door with Replaceable Curtain and DSP Servo System online

Quick Access Component PVC High Speed Door with Replaceable Curtain and DSP Servo System

Chat Now
Good price Motorized Servo Drive PVC High Speed Door for 1000+ Cycles Daily with Adjustable Speed 0.8-2.0 m/s online

Motorized Servo Drive PVC High Speed Door for 1000+ Cycles Daily with Adjustable Speed 0.8-2.0 m/s

Chat Now
Contact Us
86--18021983369
yohao260105@gmail.com
Chat Now
Product Description
Photoelectric Sensor Industrial High Speed Door For Mixed Forklift And Pedestrian Safety
In facilities where forklifts and workers share the same passages, safety is the top priority. A fast door that closes on a person or vehicle can cause serious injury and costly downtime. This Industrial High Speed Door is built around one core selling point: an integrated safety protection system. Photoelectric sensors and an optional safety bottom edge help improve operational safety, so the door reacts instantly to people and vehicles while still supporting fast, high-frequency traffic.
Integrated Safety Protection Highlights
Photoelectric Sensors
Infrared photoelectric sensors monitor the doorway and stop or reverse the door when movement is detected in its path.
Optional Safety Bottom Edge
A soft safety bottom edge reverses the door on contact, protecting people and goods below.
Reverse Wiring Protection
A built-in safety circuit prevents the door from closing against an obstruction.
Emergency Stop
A standard emergency stop switch halts the door instantly when needed.
Manual Override
In power failure or malfunction, the door can be opened manually with a wrench.
LED Fault Display
Clear fault display helps operators quickly identify and resolve safety issues.
Why It Improves Operational Safety
  • Protects People And Vehicles: Sensors and the soft bottom edge reduce the risk of collision in mixed traffic.
  • Confident, Fast Traffic: Workers and forklifts can move through knowing the door reacts to them.
  • Fewer Accidents, Less Downtime: Proactive safety systems reduce incidents and interruptions.
  • Clear Status At A Glance: LED fault display and emergency stop support safe daily operation.
  • Reliable And Durable: Robust components keep the safety system dependable shift after shift.
Typical Applications
  • Warehouses with mixed forklift and pedestrian traffic
  • Shared passages in manufacturing plants
  • Loading and unloading zones with vehicle and worker flow
  • Distribution centers with high traffic volumes
  • Any passage where operational safety is critical
Product Specifications
Safety System Photoelectric sensors, optional safety bottom edge, reverse wiring protection, emergency stop
Material PVC curtain / Galvanized steel (standard), stainless steel optional
Max Door Size Width 1000-6000 mm, Height 1500-6000 mm
Operating Speed Opening 0.8-2.0 m/s (adjustable); Closing 0.5-0.8 m/s (adjustable)
Curtain Thickness 0.8 / 1.2 / 1.5 / 2.0 mm
Motor Power 0.75-1.5 KW (depending on size and speed)
Sealing System Side brush seals with bottom airbag / EPDM seal
Control System DSP-based servo system with LED fault display
Temperature Range -10°C to 60°C
Power Requirements 220V/13A single-phase, 50Hz-60Hz, IP54 control box
Frequently Asked Questions
  • How do the sensors improve safety? Photoelectric sensors detect movement in the doorway and stop or reverse the door to avoid contact.
  • What is the safety bottom edge? An optional soft edge that reverses the door on contact, protecting people and goods.
  • Can it be customized? Yes, dimensions, curtain material, safety options, and activation methods are customizable.
Contact Us
Changzhou YOHO Industrial Door Co., Ltd.
Email: yohao260105@gmail.com
WhatsApp: +8618021983369
OEM & ODM welcome. Contact us today for factory-direct pricing and customized safety solutions.
