Place of Origin:
China
Brand Name:
YOHO
Certification:
ISO 9001/CE
Model Number:
YOHO-PVC-HSD-FC
This fast and convenient PVC industrial high speed door is designed for facilities that need quick access without complicated installation or heavy maintenance. With a simple bolt-on structure and an adjustable high-speed drive, the door is ready for service in a short time and keeps working reliably day after day.
It combines fast and convenient operation, simple installation, convenient maintenance and wide application flexibility, suitable for logistics centers, warehouses, garages, car washes, workshops and factories.
| Parameter | Description |
|---|---|
| Opening Speed | 0.8-2.0 m/s (adjustable) |
| Curtain Material | High-grade PVC, 0.9 mm standard |
| Frame Material | Galvanized steel / stainless steel optional |
| Opening Size | Customized, width up to 6000 mm |
| Activation | Radar / magnetic loop / remote / pull switch / push button |
| Control System | PLC control with frequency inverter |
| Safety Device | Bottom safety edge, photocell, emergency stop |
| Installation | Pre-assembled, quick bolt-on assembly |
| Power Supply | 220V/380V, 50Hz/60Hz |
We are a professional high speed door manufacturer supporting OEM/ODM service and fast delivery. Contact us for a factory-direct quotation and installation guidance.
