Place of Origin:
China
Brand Name:
YOHO
Certification:
ISO 9001/CE
Model Number:
High-Speed PVC Industrial Door
Loading dock areas are among the busiest zones in industrial facilities. Frequent movement of forklifts, pallet trucks, and delivery vehicles requires door systems that respond quickly and operate reliably.
The Industrial High Speed Door is an efficient solution for loading dock environments where speed and durability are critical. This industrial fast door allows rapid access between dock areas and warehouse zones, helping reduce congestion and improve loading efficiency. Its robust construction and advanced control systems ensure smooth operation even in demanding logistics conditions.
Industrial High Speed Doors allow forklifts and vehicles to move efficiently between dock areas.
Opening speed up to 1.2 m/s
Rapid door cycle
Smooth movement system
Loading dock environments require strong and reliable door systems.
Reinforced PVC curtain
Heavy-duty guide rails
Industrial motor system
Automation improves operational efficiency in logistics areas.
Radar detection
Remote control access
PLC automation compatibility
Safety features protect workers and vehicles.
Photoelectric safety sensors
Soft bottom edge protection
Automatic obstacle detection
 |
|
Industrial High Speed Doors reduce waiting time during logistics operations.
Fast door cycles help eliminate congestion in dock areas.
Rapid closing helps minimize airflow between indoor and outdoor areas.
Industrial fast doors support efficient supply chain operations.
Installed between docks and warehouse storage zones.
Supports efficient cargo movement.
Enables fast access between unloading and sorting areas.
Improves transport and loading efficiency.
Contact Us:
Whatsapp:+8618021983369
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
| Parameter | Description |
|---|---|
| Material | PVC curtain / Galvanized steel / Stainless steel |
| Max Door Size | Door Width: 1000 mm - 6000 mm; Door Height: 1500 mm - 6000 mm |
| Operating Speed | Opening Speed: 0.8-2.0 m/s (adjustable); Closing Speed: 0.5-0.8 m/s (adjustable) |
| Curtain Material | 0.8/1.2/1.5/2.0 mm thick curtain, color options: Blue, Orange, Gray |
| Motor Power | 0.75-1.5KW (depending on size & speed) |
| Temperature Range | -10°C to 60°C (PVC); -10°C to 60°C (Steel/Stainless Steel) |
| Sealing Performance | High-quality brush seals on tracks; Bottom equipped with EPDM seal structure for better sealing |
| Wind Resistance | Max Wind Resistance: Class 6 (can be reinforced to Class 8) |
| Manual Function | In case of power failure or malfunction, the door can be manually opened with a wrench. |
| Power Requirements | 220V/13A Single-phase/50Hz-60Hz, IP54 control box, meets national electrical safety standards. |
| Insulation Protection | IP54 rating, providing water and dust protection, suitable for harsh environments. |
| Switching Methods | Standard one-button switch with emergency stop. Optional: Radar sensing, Ground magnetic sensing, Pull-rope switch, Remote control, etc. |
Yes. They are designed for high-traffic industrial environments.
Yes. Safety sensors and soft edges protect equipment and workers.
High-quality Industrial High Speed Doors are designed for long-term industrial use.
|
|
|
Looking for a reliable High Speed Industrial Door solution?
Contact Changzhou YOHO Industrial Door Co., Ltd. today, let us help you improve production efficiency, reduce downtime, and optimize material flow throughout your automotive manufacturing facility.
