Industrial High Speed Door With Enhanced Safety For Internal Factory Passages

Industrial High Speed Door With Enhanced Safety For Internal Factory Passages

pvc industrial high speed door

red industrial high speed door

Place of Origin:

China

Brand Name:

YOHO

Certification:

ISO 9001/CE

Model Number:

High-Speed PVC Industrial Door

Chat Now
Request A Quote
Industrial High Speed Door With Enhanced Safety For Internal Factory Passages
Industrial High Speed Door With Enhanced Safety For Internal Factory Passages Industrial High Speed Door With Enhanced Safety For Internal Factory Passages
Product Details
Color:
Yellow/Blue/Red/Grey/White/Transparent
Size:
3x3 M Or Customized (max Size:6x8m)
Voitage:
380V Or 220V
Name:
High-Speed PVC Industrial Door
Panel Material:
Anti-skid Checkered Plate
Material:
PVC Curtain / Galvanized Steel / Stainless Steel
Power:
0.75-1.5KW
Door Width:
1000 Mm - 6000 Mm
Door Height:
1500 Mm - 6000 Mm
Application:
Internal Factory Passages
Highlight:

pvc industrial high speed door

,

red industrial high speed door

Payment & Shipping Terms
Minimum Order Quantity
IUNIT
Price
negotiation
Packaging Details
plywood package
Delivery Time
10~15DAYS
Payment Terms
T/T
Supply Ability
300 unit per month
Related Products
Good price Excellent Sealing & Automatic High-Speed Industrial Fast Door With Durable PVC Curtain For Industrial Workshops online video

Excellent Sealing & Automatic High-Speed Industrial Fast Door With Durable PVC Curtain For Industrial Workshops

Chat Now
Good price High-Speed & High-Frequency Performance Industrial PVC High Speed Door for Factory Internal Access online video

High-Speed & High-Frequency Performance Industrial PVC High Speed Door for Factory Internal Access

Chat Now
Good price Opening Speed Up To 2.0m/s PVC High Speed Door For Logistics Centers online video

Opening Speed Up To 2.0m/s PVC High Speed Door For Logistics Centers

Chat Now
Good price Industrial Fast Door With High-Speed Operation And High-Frequency Performance For Industrial Production Areas online video

Industrial Fast Door With High-Speed Operation And High-Frequency Performance For Industrial Production Areas

Chat Now
Contact Us
86--18021983369
yohao260105@gmail.com
Chat Now
Product Description

Industrial High Speed Door With Enhanced Safety For Internal Factory Passages

The Industrial High Speed Door for Internal Factory Passages is designed to optimize internal traffic flow, safety, and environmental separation within manufacturing facilities.

In internal factory passages, forklifts, carts, AGVs, and personnel move frequently between different workshops and functional zones. This high speed door features fast opening speed, precise servo control, and reliable safety protection, ensuring smooth passage while maintaining separation between production areas.

Product Advantages

1️⃣ Smooth Internal Traffic Flow

  • Fast opening and closing reduce congestion
  • Supports high-frequency movement of forklifts and personnel

2️⃣ Effective Area Separation

  • Helps control dust, noise, airflow, and temperature between workshops
  • Improves production organization and management

3️⃣ Enhanced Safety for Workers & Equipment

  • Multiple safety devices prevent collision and injury
  • Stable operation reduces mechanical impact

4️⃣ Energy Efficiency & Cost Control

  • Minimizes unnecessary air exchange
  • Reduces HVAC energy consumption in production areas
Industrial High Speed Door With Enhanced Safety For Internal Factory Passages 0 Industrial High Speed Door With Enhanced Safety For Internal Factory Passages 1

High-Frequency Operation & Safety Protection

Internal passages often experience constant traffic throughout the day.

  • Servo Motor System: Supports thousands of open/close cycles per day
  • Fast Opening Speed: Up to 1.5 m/s, reducing waiting time
  • Infrared Sensors: Detect people and vehicles to prevent collisions
  • Bottom Soft Safety Edge: Ensures immediate rebound upon contact

This combination ensures safe, efficient, and uninterrupted internal logistics flow.

Applications

  • Internal factory passages
  • Workshop-to-workshop connections
  • Production line access points
  • Warehouse-to-production area passages
  • AGV and forklift traffic zones

Product Specifications

Parameter Description
Material PVC curtain / Galvanized steel / Stainless steel
Max Door Size Door Width: 1000 mm - 6000 mm; Door Height: 1500 mm - 6000 mm
Operating Speed Opening Speed: 0.8-2.0 m/s (adjustable); Closing Speed: 0.5-0.8 m/s (adjustable)
Curtain Material 0.8/1.2/1.5/2.0 mm thick curtain, color options: Blue, Orange, Gray
Motor Power 0.75-1.5KW (depending on size & speed)
Temperature Range -10°C to 60°C (PVC); -10°C to 60°C (Steel/Stainless Steel)
Sealing Performance High-quality brush seals on tracks; Bottom equipped with EPDM seal structure for better sealing
Wind Resistance Max Wind Resistance: Class 6 (can be reinforced to Class 8)
Manual Function In case of power failure or malfunction, the door can be manually opened with a wrench.
Power Requirements 220V/13A Single-phase/50Hz-60Hz, IP54 control box, meets national electrical safety standards.
Insulation Protection IP54 rating, providing water and dust protection, suitable for harsh environments.
Switching Methods Standard one-button switch with emergency stop. Optional: Radar sensing, Ground magnetic sensing, Pull-rope switch, Remote control, etc.

Contact Us:

Email:yohao260105@gmail.com

Whatsapp:+8618021983369

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service

FAQ

Q1: Why are high speed doors suitable for internal factory passages?

They allow fast and safe movement while maintaining separation between different functional areas inside the factory.

Q2: Can the door handle frequent forklift traffic?

Yes. The door is designed for high-frequency operation and can be activated by radar or ground loop sensors for forklifts.

Q3: Does the door help with dust and noise control?

Yes. Tight sealing and fast operation help reduce dust, airflow, and noise transfer between areas.

Q4: Can the door be customized for different passage sizes?

Yes. Door dimensions, materials, control systems, and safety options can be customized.

Industrial High Speed Door With Enhanced Safety For Internal Factory Passages 2

Industrial High Speed Door With Enhanced Safety For Internal Factory Passages 3


Contact Us Today

Contact Changzhou YOHO Industrial Door Co., Ltd. for customized solutions, factory-direct pricing, and professional technical support.
