Place of Origin:
China
Brand Name:
YOHO
Certification:
ISO 9001/CE
Model Number:
High-Speed PVC Industrial Door
In automated factories and modern production facilities, even a few seconds of delay at an equipment passage can affect the entire production process. Traditional doors often become bottlenecks, slowing down AGV traffic, interrupting material flow, and increasing the risk of contamination between different production zones.
The PVC High Speed Door is designed specifically for equipment passages where efficiency, automation, and environmental control are critical. By combining high-speed operation, intelligent activation systems, and reliable sealing performance, this Industrial Fast Door helps manufacturers maintain continuous production flow, improve automation efficiency, and reduce unnecessary downtime.
Slow-opening doors can force AGVs, forklifts, and conveyor systems to stop and wait, reducing overall production efficiency.
Open passages allow dust and airborne particles to move between equipment areas and production lines.
Different manufacturing processes often require separate temperature, humidity, or cleanliness levels.
Traditional rigid doors can be easily damaged by equipment traffic and require costly repairs.
Fast opening and closing speeds help maintain continuous movement of materials and equipment.
AGVs and forklifts can pass through without unnecessary delays.
The door can be connected to automated guided vehicles and smart logistics systems.
Integrates seamlessly with factory automation and production management systems.
Helps separate production zones and improve cleanliness.
Supports stable environmental conditions between different work areas.
The soft curtain minimizes repair costs caused by accidental impacts.
Ensures reliable long-term operation with minimal downtime.
Supports continuous operation of production lines and equipment.
Allows automated systems to operate without interruption.
Minimizes repair expenses and production losses.
Optional vision panels help personnel and vehicle operators identify approaching traffic.
Contact Us:
Whatsapp:+8618021983369
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
| Parameter | Description |
|---|---|
| Material | PVC curtain / Galvanized steel / Stainless steel |
| Max Door Size | Door Width: 1000 mm - 6000 mm; Door Height: 1500 mm - 6000 mm |
| Operating Speed | Opening Speed: 0.8-2.0 m/s (adjustable); Closing Speed: 0.5-0.8 m/s (adjustable) |
| Curtain Material | 0.8/1.2/1.5/2.0 mm thick curtain, color options: Blue, Orange, Gray |
| Motor Power | 0.75-1.5KW (depending on size & speed) |
| Temperature Range | -10°C to 60°C (PVC); -10°C to 60°C (Steel/Stainless Steel) |
| Sealing Performance | High-quality brush seals on tracks; Bottom equipped with EPDM seal structure for better sealing |
| Wind Resistance | Max Wind Resistance: Class 6 (can be reinforced to Class 8) |
| Manual Function | In case of power failure or malfunction, the door can be manually opened with a wrench. |
| Power Requirements | 220V/13A Single-phase/50Hz-60Hz, IP54 control box, meets national electrical safety standards. |
| Insulation Protection | IP54 rating, providing water and dust protection, suitable for harsh environments. |
| Switching Methods | Standard one-button switch with emergency stop. Optional: Radar sensing, Ground magnetic sensing, Pull-rope switch, Remote control, etc. |
Supports uninterrupted manufacturing processes.
Improves efficiency of automated material handling systems.
Reduces bottlenecks between production stages.
Maintains safety and environmental control around robotic systems.
Helps reduce dust and contamination risks.
Because it reduces waiting time, supports automation systems, and improves production efficiency.
Yes. The door can be integrated with AGV, AMR, PLC, conveyor systems, and other automation equipment.
Its high-speed operation and sealing system help limit dust, particles, and airflow between production zones.
Yes. It is specifically designed for high-frequency industrial applications and automated manufacturing environments.
Looking for a reliable PVC High Speed Door solution for your equipment passage or automated production line?
Contact Changzhou YOHO Industrial Door Co., Ltd. today for:
Let us help you improve production efficiency, reduce downtime, and create a smarter manufacturing environment.
|
|
|
