Place of Origin:
China
Brand Name:
YOHO
Certification:
ISO 9001/CE
Model Number:
High-Speed PVC Industrial Door
In busy warehouses and logistics centers, every second matters. Slow doors can create forklift congestion, increase loading delays, and reduce overall operational efficiency. Frequent opening of traditional doors also causes significant energy loss, allowing dust, insects, and outside air to enter the facility.
The PVC High Speed Door is designed specifically to solve these challenges. With fast opening speeds, intelligent automatic controls, and excellent sealing performance, this Industrial Fast Door helps warehouses improve traffic flow, reduce operating costs, and maintain a cleaner working environment. Whether used in distribution centers, e-commerce warehouses, or internal logistics passages, it provides a reliable solution for high-frequency operations.
Traditional doors often cannot keep up with busy forklift traffic, creating bottlenecks between warehouse zones.
Long door opening times allow conditioned air to escape, increasing heating and cooling costs.
Warehouse doors are regularly exposed to accidental collisions that lead to costly repairs.
Open passages allow contaminants to enter storage and packaging areas.
Opening speeds of up to 2.0 m/s allow forklifts and logistics vehicles to move efficiently without interruption.
Faster access helps improve loading, unloading, and internal transportation efficiency.
The door closes quickly after each passage, helping maintain indoor temperatures.
Sealing systems reduce dust, insects, and unwanted airflow.
The soft PVC curtain can absorb minor impacts, reducing maintenance expenses.
Less damage means fewer interruptions to warehouse operations.
The door automatically opens when vehicles approach.
Can be integrated with AGV routes, conveyor systems, and warehouse automation solutions.
Supports smooth movement of forklifts, pallet trucks, and warehouse personnel.
Helps maintain a stable warehouse environment and reduce utility expenses.
Optional vision panels help operators identify traffic on both sides of the door.
Suitable for modern logistics facilities using automated equipment.
| Parameter | Description |
|---|---|
| Material | PVC curtain / Galvanized steel / Stainless steel |
| Max Door Size | Door Width: 1000 mm - 6000 mm; Door Height: 1500 mm - 6000 mm |
| Operating Speed | Opening Speed: 0.8-2.0 m/s (adjustable); Closing Speed: 0.5-0.8 m/s (adjustable) |
| Curtain Material | 0.8/1.2/1.5/2.0 mm thick curtain, color options: Blue, Orange, Gray |
| Motor Power | 0.75-1.5KW (depending on size & speed) |
| Temperature Range | -10°C to 60°C (PVC); -10°C to 60°C (Steel/Stainless Steel) |
| Sealing Performance | High-quality brush seals on tracks; Bottom equipped with EPDM seal structure for better sealing |
| Wind Resistance | Max Wind Resistance: Class 6 (can be reinforced to Class 8) |
| Manual Function | In case of power failure or malfunction, the door can be manually opened with a wrench. |
| Power Requirements | 220V/13A Single-phase/50Hz-60Hz, IP54 control box, meets national electrical safety standards. |
| Insulation Protection | IP54 rating, providing water and dust protection, suitable for harsh environments. |
| Switching Methods | Standard one-button switch with emergency stop. Optional: Radar sensing, Ground magnetic sensing, Pull-rope switch, Remote control, etc. |
Contact Us:
Whatsapp:+8618021983369
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Ideal for facilities operating multiple loading shifts.
Supports high-volume product movement.
Improves environmental control and workflow management.
Enhances dock operation efficiency.
Because it opens faster, reduces energy loss, improves logistics efficiency, and requires less maintenance.
Yes. It is specifically designed for high-frequency warehouse operations and continuous daily use.
Yes. The door can be integrated with radar sensors, AGV systems, PLC controls, and conveyor lines.
Looking for a reliable PVC High Speed Door supplier for your warehouse or logistics project?
Contact Changzhou YOHO Industrial Door Co., Ltd. today for:
Let us help you improve warehouse efficiency, reduce operating costs, and create a smarter logistics environment.
|
|
|
