Place of Origin:
China
Brand Name:
YOHO
Certification:
ISO 9001/CE
Model Number:
High-Speed PVC Industrial Door
Factories and warehouses require fast, reliable access solutions to keep materials, forklifts, and personnel moving efficiently. The High-Speed PVC Industrial Door is designed for high-frequency industrial environments where productivity, energy efficiency, and environmental control are critical. With rapid opening speeds, a durable PVC curtain, and intelligent control options, this industrial high speed door helps improve workflow while reducing energy loss and maintenance costs.
Forklifts and workers often experience delays when traditional doors cannot keep up with busy operations.
Reduced throughput
Doors that stay open too long allow conditioned air to escape.
Increased Utility Costs
Contamination Risks
Poor Working Conditions
Door Damage
Unexpected Downtime
Improve Traffic Flow
Increase Operational Efficiency
Flexible Impact Resistance
Long Service Life
Automatic Activation
Automation Integration
Reduce Air Exchange
Lower Operating Costs
Faster Material Handling
Better Temperature Control
Improved Visibility
Reliable Operation
| Parameter | Description |
|---|---|
| Material | PVC curtain / Galvanized steel / Stainless steel |
| Max Door Size | Door Width: 1000 mm - 6000 mm; Door Height: 1500 mm - 6000 mm |
| Operating Speed | Opening Speed: 0.8-2.0 m/s (adjustable); Closing Speed: 0.5-0.8 m/s (adjustable) |
| Curtain Material | 0.8/1.2/1.5/2.0mm thick curtain, color options: Blue, Orange, Gray |
| Motor Power | 0.75-1.5KW (depending on size & speed) |
| Temperature Range | -10°C to 60°C (PVC); -10°C to 60°C (Steel/Stainless Steel) |
| Sealing Performance | High-quality brush seals on tracks; Bottom equipped with EPDM seal structure for better sealing |
| Wind Resistance | Max Wind Resistance: Class 6 (can be reinforced to Class 8) |
| Manual Function | In case of power failure or malfunction, the door can be manually opened with a wrench. |
| Power Requirements | 220V/13A Single-phase/50Hz-60Hz, IP54 control box, meets national electrical safety standards. |
| Insulation Protection | IP54 rating, providing water and dust protection, suitable for harsh environments. |
| Switching Methods | Standard one-button switch with emergency stop. Optional: Radar sensing, Ground magnetic sensing, Pull-rope switch, Remote control, etc. |
Contact Us:
Whatsapp:+8618021983369
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Production Area Access
High-Traffic Passages
Efficient Goods Handling
Temperature Retention
Environmental Separation
Material Transfer Zones
Typical opening speeds range from 0.8 m/s to 1.5 m/s.
Designed for hundreds of operating cycles per day.
Compatible with AGV systems, PLC controls, and conveyor lines.
OEM and project-specific customization are available.
Looking for a reliable industrial high speed door solution for your factory or warehouse?
Contact Changzhou YOHO Industrial Door Co., Ltd. for customized solutions, competitive pricing, OEM support, and professional technical assistance.
|
|
|
