Hydraulic Dock Plate Leveler Blue For Food / Beverage Distribution Centers

Hydraulic Dock Plate Leveler Blue For Food / Beverage Distribution Centers

MOQ: IUNIT
Price: negotiation
Standard Packaging: plywood package
Delivery Period: 10~15DAYS
Payment Method: T/T
Supply Capacity: 300 unit per month
Detail Information
Place of Origin
China
Brand Name
YOHO
Certification
ISO 9001/CE
Model Number
Hydraulic Dock Leveler
Product Name:
Dock Plate Leveler
Color:
Black Or Blue Or Grey
Voitage:
380V
Lifting Speed:
0.05-0.09m/s
Size:
2000*2000*600 Or 2000*2500*600
Working Temperature:
-35℃~+50℃
Colors:
Blue ,grey ,customized
Panel Material:
Anti-skid Checkered Plate
Application:
Food & Beverage Distribution Centers
Highlight:

Hydraulic Dock Plate Leveler

,

Dock Plate Leveler Blue

,

Distribution Centers Dock Plate Leveler

Product Description

Efficient Loading Dock Levelers for Food & Beverage Distribution Centers

Food & beverage distribution centers require fast, safe, and hygienic handling of products. Our Loading Dock Levelers are designed to ensure smooth cargo transfer between docks and delivery vehicles, supporting high-frequency operations while maintaining safety and compliance.
As an essential part of dock leveling systems, these solutions improve dock efficiency, reduce truck idle time, and optimize the workflow in food and beverage distribution centers.


What is a Loading Dock Leveler?

A Loading Dock Leveler is a key component of loading dock equipment that bridges the height gap between warehouse floors and delivery trucks.
In food and beverage operations, dock levelers allow forklifts, pallet trucks, and automated handling equipment to safely move products, including pallets of beverages, packaged foods, and refrigerated goods, across loading bays.

Common types include hydraulic dock levelers, mechanical dock levelers, electric dock levelers, and adjustable dock levelers, designed to meet different operational needs and temperature-controlled environments.


Product Specifications

rated bearing capacity of the platform

6.0t

(dynamic)

8.0t

(static)

Working temperature

-35℃~+50℃

Driving voltage

380V,3phase,50HZ

Main panel material

8mm thick embossed anti slip plate

Main panel support

C-type bending parts

Building board material

14mm thick embossed anti slip steel plate

Bottom frame

#8channel steel and angle steel

Safety barriers on both sides

3mm steel plate and 1.2mm hot-dip galvanized steel plate

Electric hydraulic system

Includes main lift cylinder

Safety system

  • after an unexpected power outage,only the manual operation platform will restart
  • circuit locking safety emergency stop device,which can stop the platform at any position through the emergency stop button on the control box)
  • Yellow/black warning strips are affixed on both sides of the safety barrier

Collision avoidance system

Anti collision rubber block :two pieces,welded to the front end of the platform

Structural Diagram

Hydraulic Dock Plate Leveler Blue For Food / Beverage Distribution Centers 0

Key Features and Advantages for Food & Beverage Operations

High Load Capacity for Continuous Operations

Our industrial dock levelers handle pallets of beverages, packaged foods, and other bulk items with ease.
Reinforced steel construction ensures reliability for high-volume dock leveling systems in busy food and beverage centers.


Fast and Automated Dock Positioning

Hydraulic loading dock levelers and automatic dock levelers allow rapid deployment and adjustment, reducing truck waiting times and accelerating product turnover, especially during peak delivery hours.


Safety and Hygiene Features

Safety dock levelers include anti-slip surfaces, stable lip design, and emergency stop features.
These features protect operators and cargo while supporting hygienic handling practices in temperature-controlled or dry storage areas.


Application Scenarios in Food & Beverage Distribution Centers

Loading dock levelers are ideal for:

  • Beverage distribution warehouses

  • Packaged food fulfillment centers

  • Cold chain / refrigerated distribution centers

  • High-frequency shipping docks

  • Bulk pallet transfer zones

  • Multi-temperature storage loading bays

They are essential for industrial loading solutions and dock leveling systems in fast-moving food logistics operations.


Why Choose Our Dock Levelers for Food & Beverage Centers?

Reliable Performance in High-Traffic Environments

Each industrial dock leveler is tested for durability, load capacity, and reliability to ensure consistent operation in high-frequency distribution centers.


Flexible and Customizable Solutions

We provide tailored dock leveling systems based on dock size, load requirements, and environmental conditions.
Options include pit levelers, manual dock levelers, and portable dock levelers, suitable for both dry and refrigerated areas.


Comprehensive Maintenance and Support

Our team provides professional guidance, dock leveler maintenance, and long-term technical support.
We also supply accessories such as dock bumpers, dock seals & shelters, and dock shelter systems to optimize dock safety and efficiency.


Frequently Asked Questions (FAQ)

Q: Can dock levelers operate in refrigerated areas?
A: Yes, our dock levelers are suitable for both ambient and temperature-controlled zones.

Q: Are custom sizes available for food distribution docks?
A: Yes, we offer adjustable dock levelers to match specific dock layouts and load requirements.

Q: Can dock levelers integrate with dock shelters or bumpers?
A: Yes, they can be combined with dock bumpers, dock seals & shelters, and dock shelter systems for a complete dock solution.


Get a Quote and Project Support

Contact Our Sales Team

For Loading Dock Levelers in Food & Beverage Distribution Centers, contact our sales team today.
We provide professional consultation, technical recommendations, and competitive pricing for distribution operators.



Hydraulic Dock Plate Leveler Blue For Food / Beverage Distribution Centers 1

Hydraulic Dock Plate Leveler Blue For Food / Beverage Distribution Centers 2
