Specialized Loading Dock Leveler For Cold Storage / Refrigerated Warehouse

Specialized Loading Dock Leveler For Cold Storage / Refrigerated Warehouse

MOQ: IUNIT
Price: negotiation
Standard Packaging: plywood package
Delivery Period: 10~15DAYS
Payment Method: T/T
Supply Capacity: 300 unit per month
Detail Information
Place of Origin
China
Brand Name
YOHO
Certification
ISO 9001/CE
Model Number
Hydraulic Dock Leveler
Product Name:
Hydraulic Dock Leveler/Dock Leveler
Color:
Black Or Blue Or Grey
Size:
2000*2000*600 Or 2000*2500*600
Voitage:
380V
Panel Material:
Anti-skid Checkered Plate
Lifting Speed:
0.05-0.09m/s
Working Temperature:
-35℃~+50℃
Colors:
Blue ,grey ,costomized
Application:
Cold Storage & Refrigerated Warehouses
Highlight:

cold storage loading dock leveler

,

refrigerated warehouse dock leveler

,

heavy-duty loading dock leveler

Product Description

Specialized Loading Dock Levelers for Cold Storage & Refrigerated Warehouses

Cold storage and refrigerated warehouses require precise, safe, and efficient cargo handling under controlled temperatures. Our Loading Dock Levelers are engineered to ensure smooth transfer of pallets, crates, and containers between dock platforms and refrigerated trucks.
As a core component of dock leveling systems, these solutions minimize truck idle time, maintain product integrity, and support continuous operations in cold storage and refrigerated warehouses.

Key Features and Advantages for Refrigerated Warehouses

High Load Capacity in Low-Temperature Environments

Our industrial dock levelers are designed to handle pallets of frozen and chilled goods while maintaining durability in low temperatures.
Reinforced steel construction ensures long-term performance in cold storage dock leveling systems.

Fast and Automated Dock Operations

Hydraulic loading dock levelers and automatic dock levelers allow rapid deployment, reducing truck waiting times and accelerating loading and unloading cycles, even in temperature-sensitive operations.

Safety and Anti-Slip Features for Cold Storage

Safety dock levelers include anti-slip surfaces, secure lip design, and emergency stop functions.
These features prevent accidents in slippery, refrigerated environments, protecting operators and temperature-sensitive cargo.

Product Specifications

Rated bearing capacity of the platform 6.0t (dynamic) 8.0t (static)
Working temperature -35℃~+50℃
Driving voltage 380V,3phase,50HZ
Main panel material 8mm thick embossed anti slip plate
Main panel support C-type bending parts
Building board material 14mm thick embossed anti slip steel plate
Bottom frame #8channel steel and angle steel
Safety barriers on both sides 3mm steel plate and 1.2mm hot-dip galvanized steel plate
Electric hydraulic system Includes main lift cylinder
Safety system
  1. after an unexpected power outage,only the manual operation platform will restart
  2. circuit locking safety emergency stop device,which can stop the platform at any position through the emergency stop button on the control box)
  3. Yellow/black warning strips are affixed on both sides of the safety barrier
Collision avoidance system Anti collision rubber block :two pieces,welded to the front end of the platform

How Dock Levelers Work in Cold Storage

Dock levelers lift the platform and deploy the dock leveler lip onto the truck bed, forming a secure ramp for forklifts, pallet movers, and cargo carts.
They accommodate trucks of varying heights, enabling fast, consistent operations.
Operations may be manual, hydraulic, air-powered, or automatic, supporting continuous cold chain logistics.

Structural Diagram

Specialized Loading Dock Leveler For Cold Storage / Refrigerated Warehouse 0

Frequently Asked Questions (FAQ)

Q: Can dock levelers operate safely in sub-zero temperatures?
A: Yes, our dock levelers are designed for cold storage and refrigerated warehouses, maintaining functionality in freezing conditions.

Q: Are custom sizes available for refrigerated docks?
A: Yes, we provide adjustable dock levelers to match specific dock layouts and load requirements.

Q: Can dock levelers integrate with dock shelters and bumpers in cold storage?
A: Yes, they can be combined with dock bumpers, dock seals & shelters, and dock shelter systems for complete solutions.

Get a Quote and Cold Chain Support

Contact Our Sales Team

For Loading Dock Levelers in Cold Storage & Refrigerated Warehouses, contact our sales team today.
We provide professional consultation, technical recommendations, and competitive pricing for cold chain logistics operators.

Contact Us:

Email:yohao260105@gmail.com

Whatsapp:+8618021983369

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service

Specialized Loading Dock Leveler For Cold Storage / Refrigerated Warehouse 1 Specialized Loading Dock Leveler For Cold Storage / Refrigerated Warehouse 2

Factory Strength & Certifications

Changzhou YOHO Industrial Door Co.,Ltd. is a professional manufacturer of loading dock equipment and industrial door systems, specializing in Loading Dock Levelers, Dock Shelters, High Speed Doors, and Sectional Overhead Doors for global industrial applications.

Our factory is equipped with advanced CNC processing machines, precision cutting systems, and professional assembly lines to ensure stable product quality and high production efficiency. Every Loading Dock Leveler is strictly manufactured under standardized processes and tested for load capacity, structural strength, and operational safety before delivery.

Specialized Loading Dock Leveler For Cold Storage / Refrigerated Warehouse 3 Specialized Loading Dock Leveler For Cold Storage / Refrigerated Warehouse 4

We have obtained multiple international certifications, ensuring our products meet global industrial safety and quality standards. With a strong quality control system from raw material selection to final inspection, we guarantee reliable performance even under high-frequency and heavy-duty working conditions.

In addition, we support OEM & ODM customization services, including platform size, load capacity, structural design, and control systems, to meet different project requirements from distributors, contractors, and end users.

Why Choose Us

  • Advanced manufacturing equipment and skilled engineering team
  • Strict quality control system with certified production standards
  • Reliable heavy-duty performance for industrial environments
  • Full OEM/ODM customization capability
  • Export experience to global warehouse and logistics projects

Specialized Loading Dock Leveler For Cold Storage / Refrigerated Warehouse 5

Contact Us

Looking for a reliable Loading Dock Leveler supplier from China?
Contact Changzhou YOHO Industrial Door Co.,Ltd. today to get technical support, drawings, and a competitive quotation for your project. Our team is ready to provide professional solutions for your loading dock system.
