Custom-Size Configurable Industrial Sectional Overhead Door for Non-Standard Workshop Openings with 24dB Sound Insulation

Custom Sizes And Options

Non-Standard Door Sizes

Configurable Overhead Door Options

Place of Origin:

China

Brand Name:

YOHO

Certification:

ISO 9001/CE

Model Number:

Sectional Overhead Door

Chat Now

Request A Quote

Product Details

Product Name:

Sectional Overhead Door

Customization:

Custom Sizes And Options

Max Size:

Door Width 1000-8000mm, Height 1500-10000mm

Panel Material Options:

SUS 304 Stainless Steel / Color-Coated Steel Plate

Panel Thickness Options:

40mm / 50mm / 80mm

Color Options:

Custom Colors Available

Accessory Options:

Vision Panels, Pedestrian Door

Wind Resistance:

Level 7-8

Sound Insulation:

24dB

Application:

Non-Standard Workshop Openings

Highlight:

Custom Sizes And Options

Non-Standard Door Sizes

Configurable Overhead Door Options

Payment & Shipping Terms

Minimum Order Quantity

1 Unit

Price

Negotiable

Packaging Details

Plywood case

Delivery Time

10-15 Days

Payment Terms

T/T

Supply Ability

300 Units per Month

Flexible Lift Configuration Industrial Sectional Overhead Door for Low-Headroom Building Openings with 24dB Sound Insulation

Chat Now

Anti-Drop Protection Industrial Sectional Overhead Door with Wire-Rope Anti-Break and Spring Anti-Broken Devices

Chat Now

Anti-Drop Protection Industrial Sectional Overhead Door with Wind Resistance Level 7-8 and 24dB Sound Insulation

Chat Now

Anti-Pinch Anti-Drop Quiet Operation Industrial Sectional Overhead Door for Safety Facility Entrances

Chat Now

86--18021983369

yohao260105@gmail.com

Chat Now

Product Description

Custom-Size Configurable Industrial Sectional Overhead Door For Non-Standard Workshop Openings

A Custom-Size Configurable Industrial Sectional Overhead Door is made to order for non-standard workshop openings. Where a stock door will not fit, our custom sizes and options allow the width, height, panel material, color, and accessories to be specified so the door matches the building exactly.

Made to Fit Awkward Openings

Workshops often have opening dimensions and clearances that differ from standard sizes. The custom sizes and options service solves this by manufacturing each door to the required dimensions and configuration. Choose the panel build, finish, and optional fittings, and the door arrives ready to install in the specific opening.

Key Advantages

Precise Custom Dimensions

Widths from 1000mm to 8000mm and heights from 1500mm to 10000mm can be produced to match each workshop opening.

Multiple Configuration Options

Set the panel material and thickness, color, and add accessories such as vision panels or pedestrian doors.

Reliable Sealing at Any Size

All-round EPDM sealing and insulated panels are maintained regardless of door dimensions.

Balanced Operation for Large Doors

Torsion-spring counterbalancing keeps even large custom doors smooth and light to operate.

Product Specifications

Panel Material	SUS 304 Stainless Steel / Color-Coated Steel Plate (options)
Panel Thickness	40mm / 50mm / 80mm (options)
Max Size	Door width 1000-8000mm, height 1500-10000mm (custom)
Color	Custom colors available
Optional Accessories	Vision panels, pedestrian door
Guiding Rail	Galvanized steel, 2mm
Wind Resistance	Level 7-8
Speed	0.2-0.4m/s
Torsion Spring Life	30,000+ cycles
Sound Insulation	24dB
Power Supply	380V 50Hz / 220V 50Hz
Operating	Automatic with manual chain hoist backup

Typical Applications

Non-standard workshop openings
Renovated or irregular building entrances
Projects with off-standard dimensions
Workshops needing specific door configurations
Facilities upgrading doors in existing openings

Frequently Asked Questions

Can you make a door for a non-standard opening?

Yes. Each door can be manufactured to the exact dimensions of the workshop opening.

What options are available?

Panel material, thickness, color, vision panels, and pedestrian doors can be selected as needed.

Which panel materials and thicknesses are available?

Panels are offered in SUS 304 stainless steel or color-coated steel plate, with 40mm, 50mm, or 80mm thickness options.

Is the sealing maintained on custom sizes?

Yes. All-round EPDM sealing and insulated panels are applied to every door regardless of size.

We provide technical consultation, OEM services, and bulk order solutions for custom-size configurable industrial sectional overhead doors for non-standard workshop openings.
