Name: Space-Saving Vertical-Opening Industrial Sectional Overhead Door with 24dB Sound Insulation for Mezzanine Loading Zones
Brand: Changzhou YOHO Industrial Door Co., Ltd.
SKU: Sectional Overhead Door
Price: negotiable USD
Availability: InStock

Home > products > Sectional Overhead Door >

Space-Saving Vertical-Opening Industrial Sectional Overhead Door with 24dB Sound Insulation for Mezzanine Loading Zones

Vertical Lift Space Saving Door

Mezzanine Sectional Overhead Door

Compact Track Vertical Opening

Place of Origin:

China

Brand Name:

YOHO

Certification:

ISO 9001/CE

Model Number:

Sectional Overhead Door

Chat Now

Request A Quote

Product Details

Product Name:

Sectional Overhead Door

Opening Type:

Vertical-Opening (Ceiling Track)

Panel Material:

SUS 304 Stainless Steel / Color-Coated Steel Plate

Panel Thickness:

40mm / 50mm / 80mm

Wind Resistance:

Level 7-8

Speed:

0.2-0.4m/s

Torsion Spring:

30,000+ Cycles

Sound Insulation:

24dB

Application:

Mezzanine Loading Zones

Highlight:

Vertical Lift Space Saving Door

Mezzanine Sectional Overhead Door

Compact Track Vertical Opening

Payment & Shipping Terms

Minimum Order Quantity

1 Unit

Price

Negotiable

Packaging Details

Plywood case

Delivery Time

10-15 Days

Payment Terms

T/T

Supply Ability

300 Units per Month

Flexible Lift Configuration Industrial Sectional Overhead Door for Low-Headroom Building Openings with 24dB Sound Insulation

Chat Now

Anti-Drop Protection Industrial Sectional Overhead Door with Wire-Rope Anti-Break and Spring Anti-Broken Devices

Chat Now

Anti-Drop Protection Industrial Sectional Overhead Door with Wind Resistance Level 7-8 and 24dB Sound Insulation

Chat Now

Anti-Pinch Anti-Drop Quiet Operation Industrial Sectional Overhead Door for Safety Facility Entrances

Chat Now

86--18021983369

yohao260105@gmail.com

Chat Now

Product Description

Space-Saving Vertical-Opening Industrial Sectional Overhead Door For Mezzanine Loading Zones

A Space-Saving Vertical-Opening Industrial Sectional Overhead Door is designed for mezzanine-level loading zones where headroom and floor space are both at a premium. The door panels rise vertically and tuck into the ceiling void, so mezzanine walkways, staging areas, and equipment remain unobstructed.

Vertical Operation That Protects Mezzanine Space

The space-saving vertical opening design keeps the door clear of mezzanine staging lanes and elevated work platforms. Because the panels lift straight up, no outward or sideways clearance is needed, which is essential in multi-level industrial buildings.

Key Advantages

Clear Mezzanine Access

Vertical travel keeps the doorway free of obstructions, protecting safe movement of goods between mezzanine levels.

Compact Headroom Fit

A low-lift track configuration can be tailored to limited ceiling height above mezzanine loading zones.

Balanced Spring System

Torsion springs counterbalance the panel weight, enabling smooth manual operation of around 140N in emergencies.

Insulation and Sealing

Double-skinned panels with EPDM all-round sealing keep temperature, dust, and noise under control across levels.

Product Specifications

Panel Material	SUS 304 Stainless Steel / Color-Coated Steel Plate
Panel Thickness	40mm / 50mm / 80mm
Guiding Rail	Galvanized steel, 2mm
Panel Width	430mm / 550mm
Wind Resistance	Level 7-8
Speed	0.2-0.4m/s
Torsion Spring Life	30,000+ cycles
Sound Insulation	24dB
Sealing	EPDM rubber all-round sealing
Max Size	Door width 1000-8000mm, height 1500-10000mm
Power Supply	380V 50Hz / 220V 50Hz
Operating	Automatic with manual chain hoist backup

Typical Applications

Mezzanine loading and staging zones
Multi-level industrial buildings
Elevated platforms and inter-level transfer points
Compact vertical warehouses
Facilities with limited ceiling clearance

Frequently Asked Questions

Is the door suitable for mezzanine levels?

Yes. The vertical-opening design keeps mezzanine access lanes clear at all times.

Which panel materials and thicknesses are available?

Panels are offered in SUS 304 stainless steel or color-coated steel plate, with 40mm, 50mm, or 80mm thickness options.

Can it work with low headroom?

Yes. Track configuration can be customized to suit restricted ceiling height.

Can the opening size be adjusted?

Yes. Width and height are fully customizable for each mezzanine project.

We provide technical consultation, OEM services, and bulk order solutions for space-saving vertical-opening industrial sectional overhead doors used in mezzanine loading zones.
