High-Frequency Heavy-Duty PVC Stacking High Speed Folding Door For Continuous Logistics Traffic

High-Frequency Heavy-Duty PVC Stacking High Speed Folding Door For Continuous Logistics Traffic

High Frequency Stacking Door

Heavy Duty PVC Folding Door

Continuous Traffic Rapid Door

Place of Origin:

China

Brand Name:

YOHO

Certification:

ISO 9001/CE

Model Number:

YOHO-STK-HF

Chat Now
Request A Quote
High-Frequency Heavy-Duty PVC Stacking High Speed Folding Door For Continuous Logistics Traffic High-Frequency Heavy-Duty PVC Stacking High Speed Folding Door For Continuous Logistics Traffic High-Frequency Heavy-Duty PVC Stacking High Speed Folding Door For Continuous Logistics Traffic
Product Details
Product Name:
High-Frequency Heavy-Duty Stacking Door
Duty Cycle:
High-frequency, 800+ Cycles Per Day
Opening Speed:
1.0-1.8 M/s (adjustable)
Curtain Type:
Segmented PVC Stacking Curtain Panels
Curtain Material:
High-grade PVC 0.9-1.2mm
Frame Material:
Galvanized Steel / Stainless Steel
Drive System:
High-torque Motor + Frequency Inverter
Control System:
PLC With Soft Start/stop
Safety Device:
Photocell + Bottom Safety Edge
Application:
Logistics Centers, Cross-dock Terminals, Busy Factory Passages
Highlight:

High Frequency Stacking Door

,

Heavy Duty PVC Folding Door

,

Continuous Traffic Rapid Door

Payment & Shipping Terms
Minimum Order Quantity
1 Unit
Price
Negotiable
Packaging Details
Plywood case with foam protection
Delivery Time
10-15 Days
Payment Terms
T/T,L/C,Western Union
Supply Ability
300 Units per Month
Related Products
Good price Corrosion Resistant Stainless Steel Frame PVC Stacking High Speed Folding Door For Washdown Facilities online

Corrosion Resistant Stainless Steel Frame PVC Stacking High Speed Folding Door For Washdown Facilities

Chat Now
Good price Smart PLC Control PVC Stacking High Speed Folding Door For Automated AGV Logistics Corridors online

Smart PLC Control PVC Stacking High Speed Folding Door For Automated AGV Logistics Corridors

Chat Now
Good price Compact Low Headroom PVC Stacking High Speed Folding Door For Building Retrofit Installations online

Compact Low Headroom PVC Stacking High Speed Folding Door For Building Retrofit Installations

Chat Now
Good price Extra-Large Wide Span PVC Stacking High Speed Folding Door For Large Industrial Openings online

Extra-Large Wide Span PVC Stacking High Speed Folding Door For Large Industrial Openings

Chat Now
Contact Us
86--18021983369
yohao260105@gmail.com
Chat Now
Product Description

Product Overview

This high-frequency heavy-duty PVC stacking high speed folding door is engineered for continuous logistics traffic that never stops. It is rated for 800+ cycles per day with a high-torque drive and soft start/stop control, keeping goods moving through cross-dock terminals and busy factory passages without bottlenecks.

Key Selling Points

Built for Nonstop Operation

  • Rated for 800+ cycles per day
  • High-torque motor and frequency inverter drive
  • Soft start and stop reduce wear on parts

Fast and Convenient Passage

  • Opening speed adjustable up to 1.8m/s
  • Automatic activation keeps forklift traffic flowing
  • Reduces waiting time at every loading cycle

Low Maintenance and Long Life

  • Heavy-duty components for continuous duty
  • Quick curtain panel replacement
  • Proven reliability in demanding logistics sites

Technical Specifications

Parameter Description
Duty Cycle High-frequency duty, 800+ cycles per day
Opening Speed 1.0-1.8 m/s (adjustable)
Curtain Type Segmented PVC stacking curtain panels
Curtain Material High-grade PVC 0.9-1.2mm
Frame Material Galvanized steel / stainless steel
Drive System High-torque motor with frequency inverter
Control System PLC with soft start/stop
Safety Device Photocell, bottom safety edge, emergency stop
Power Supply 220V/380V, 50Hz/60Hz

Typical Applications

  • Logistics and distribution centers
  • Cross-dock terminals
  • Busy factory production passages
  • E-commerce warehouse docks
  • Cold chain loading areas

Contact Us

We are a professional high speed door manufacturer supporting OEM/ODM service and customized sizes. Contact us for a factory-direct quotation and technical support.
