Place of Origin:
China
Brand Name:
YOHO
Certification:
ISO 9001/CE
Model Number:
Sectional Overhead Door
Assembly workshops require a clean, efficient, and well-organized working environment where components, production materials, and finished products move safely between workstations and storage areas. Our Industrial Sectional Overhead Door is designed to provide reliable access, excellent insulation, and smooth operation, helping manufacturers improve production efficiency while reducing energy consumption and maintenance costs. It is an ideal solution for automotive, machinery, electronics, and industrial assembly facilities.
Forklifts, AGVs, and pallet trucks move continuously between assembly lines and warehouses. A dependable door system minimizes delays and keeps production running efficiently.
Assembly processes often require stable indoor conditions. An insulated Industrial Sectional Overhead Door helps reduce heat loss while preventing dust, wind, and moisture from entering the workshop.
Unexpected door failures can interrupt production schedules. Heavy-duty components ensure reliable performance even under frequent daily operation.
The vertical lifting design keeps entrances clear, allowing personnel, forklifts, and production equipment to move safely without occupying valuable workspace.
Polyurethane-insulated sandwich panels improve thermal efficiency and help lower heating and cooling costs throughout the year.
Reinforced tracks, industrial torsion springs, and high-quality motors provide stable operation in demanding manufacturing environments.
The door is equipped with spring break protection, cable safety devices, anti-fall mechanisms, and emergency manual operation to ensure safe daily use.
|
|
|
Our Industrial Sectional Overhead Door is widely used in:
Custom options include insulated or non-insulated panels, vision windows, pedestrian doors, multiple lifting methods, and intelligent control systems.
| Item | Description |
|---|---|
| Material | SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate |
| Thickness of Panel Mateiral | 0.3 - 0.6mm Color-Coated Steel |
| Thickness of Guiding Rail | Gualvanized Steel,thickness: 2mm |
| Thickness of Panel | 40mm / 50mm / 80mm |
| Width of Panel | 430mm / 550mm |
| Density of Sandwiches | 48kg/m3 |
| Surface Treatment | Power coating,thickness of coating:30um |
| Heat Preservation | 4.5W/m.h |
| Wind Resistance | Beaufort scale 11, 28m/s |
| Noise Level: | ≤60db |
| Sound Insulation Level | 24 Db |
| Fire Retardation: | Class A |
| Speed | 10-15 m / min |
| Max Dimension | 12m * 8m |
| Sealing Performance | EPDM rubber all round sealing : two side, top, bottom,between door panels |
| Steel cord | Flexible ,3.8mm |
| Power Supply | 380V 50Hz / 220V 50Hz |
| Service Life | 10 years |
| Emergency Operation | Manual Hoist Chain to open the door in case of power off |
| Balance System | a. Balance the weight of door through the torsion spring b. Easily manual operation: 140N to open c. Spring brake device:Anti-broken device d. Service Life:100 thousand open & close e. Prolong the service life of the motor |
| Safety | Airbag protection, door anti-fall device, wire rope anti-break protection device. |
| Optional Item | Window,pedestrian door |
Contact Us:
Whatsapp:+8618021983369
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
|
|
|
Assembly workshops require reliable doors that support continuous material movement, improve workplace safety, and maintain a clean production environment. Industrial sectional overhead doors are designed to meet these operational requirements.
Yes. Insulated panels and high-performance sealing help maintain stable indoor temperatures and reduce energy consumption.
Absolutely. Heavy-duty torsion springs and reinforced hardware are designed for high-cycle industrial applications.
Yes. We offer customized dimensions, lifting configurations, insulation thicknesses, control systems, colors, windows, and pedestrian doors to match your production facility.
Looking for a dependable Industrial Sectional Overhead Door for your assembly workshop?
Changzhou YOHO Industrial Door Co., Ltd. provides factory-direct manufacturing, OEM solutions, engineering support, and competitive pricing for manufacturers, contractors, and industrial project buyers worldwide.
Upgrade your assembly workshop with a durable, energy-efficient, and high-performance industrial door solution.
